SEED CLEANING MACHINE |
TQLZ Vibrating Separator
 |
TQLZ Vibrating Separator is a new product
made by advanced technology.
It is used for cleaning the material in flour mill;
rice plant feed works, food plant, oil plant, chemical
plant and so on. Advanced design, high capacity, compact,
convenient adjust and maintenance, low noise, no pollution. |
| |
Capacity(T/h)
|
Speed
of the Motor |
Screen
Size(Cm) |
Power
(kW)
|
Weight
(Kg)
|
Packing
volume
(mm)
|
|
P-C |
C |
TQLZ63×100 |
10 |
5 |
920 |
63×100 |
2×0.25 |
360 |
1940×1485×1395 |
TQLZ100×100 |
15 |
8 |
920 |
100×100 |
2×0.25 |
420 |
1940×1810×1745 |
TQLZ100×150 |
25 |
12 |
920 |
100×150 |
2×0.37 |
520 |
2440×1810×1745 |
TQLZ100×200 |
35 |
16 |
920 |
100×200 |
2×0.37 |
540 |
2940×1810×1860 |
TQLZ150×200 |
50 |
24 |
920 |
×200 |
2×0.55 |
650 |
2940×2310×1860 |
TQSF Series Gravity Grading Stoner
|
A high efficient and multi-functional
cleaning wheat equipment. Under the synthetic action
of vibrating are sifting and air -flow. It removes
stones from the grain stream. Two layer of screen
design.
Two layer of screen design, separate the heavy impurities
and light impurities complete and efficiently, simply
cleaning procedures and improve efficiency, double
vibrators driving, balanced running, optimized designing
for better. |
| |
Capacity
(T/h)
|
Aspiration
|
Weight
(Kg)
|
Power
(kW)
|
Packing
volume
(mm)
|
| M3/min |
Pa |
TQSF63 |
3-5 |
80 |
980 |
300 |
0.25×2 |
1635×1076×2100 |
TQSF80 |
8-9 |
100 |
980 |
345 |
0.25×2 |
1635×1246×2100 |
TQSF100 |
10-11 |
135 |
980 |
400 |
0.25×2 |
1635×1446×2220 |
TQSF125 |
12-16 |
170 |
980 |
500 |
0.25×2 |
1770×1696×2220 |
TQLM Series Horizontal Rotary Sieve
|
The machine can separate large impurities(such
as stones, earth lumps, straws, pager) and smaller
impurities (loose earth, sand, small seeds) from
grain by mean of plane motion of sieve box, It has
a good sealing capacity and doesn’t pollute
air.
Advantage:
With two kinds of motion as only and rotary &
vibration
Suitable for various materials with various apertures,
such as wheat, oil paddy etc.
With automatically cleaning system. Completely separate
all kinds of impurities with three layers of sifters
and aspiration structure.
|
| |
Capacity
(T/h)
|
Power
(kw)
|
Weight
(Kg)
|
Screen Size
(Mm)
|
Packing volume
(mm)
|
TQLM63 |
3.6 |
0.55 |
600 |
642×80 |
1655×1134×1240 |
TQLM80 |
4.8 |
1.10 |
736 |
812×200 |
2420×1465×1945 |
TQLM100 |
6.0 |
1.50 |
800 |
1012×200 |
2420×1665×1945 |
TQLM125 |
7.5 |
1.50 |
856 |
1262×200 |
2420×1915×1945 |
1. 4-72 NO.4.5 Low Pressure Centrifugal Ventilator.
|
Feature: It is paired up the TQSF63 Gravity Grading
Stoner. Used to aspiration in order to separate
the materials by air suspension Pressure stability,
blowing rate sufficient. Fan stand sturdy, blade
balanced and low.
Power: 5.5 kW
Quantity: 1 set
|
2. GFY5 Rotary Seal
Feature: Used to discharge the material in the pneumatic
conveying system. The air-seal property is reliable,
the displacement of the material is easy and smooth..
Volume: 5 L Power: 0.25 Kw Quantity: 2sets
|
|
|
|
|
